Selvo 63A C Curve Four Pole MCB, GSELFPC12048, (Pack of 6)

The Selvo 63A C-Curve Four Pole MCB, model GSELFPC12048, supplied in a pack of 6, offers robust circuit protection for four-pole systems in commercial and industrial applications. It features flame-retardant construction, thermal-magnetic tripping, and complies with IS/IEC 60898-1 standards.

Key specifications include:

• Poles: Four Pole (4P)

• Rated Current: 63 Amperes

• Curve Type: C-Curve (for moderate inrush currents)

• Rated Voltage: 415V AC

• Breaking Capacity: 10 kA

• Dimensions: 8 x 8 x 9 cm

• Weight: 0.4 kg

• Mounting: DIN rail with bi-stable clip

• Terminal Capacity: Up to 35 mm² (aluminum/copper), combi-head screws (2 Nm torque)

• Protection Class: IP20

• Features: Large dual terminals, positive contact indication (red ON/green OFF), 12-plate arc chamber for rapid quenching, air circulation grooves for efficient cooling, energy limiting Class 3 design

This MCB from Selvo Electricals balances safety, durability, and ease of installation for effective circuit protection.
