Selvo 40A C Curve Four Pole MCB, GSELFPC12047, (Pack of 6)

The Selvo 40A C-Curve Four Pole MCB, model GSELFPC12047, available in a pack of 6, offers reliable overload and short-circuit protection for four-pole electrical systems, suitable for residential, commercial, and industrial applications. It features a flame-retardant PBT body, thermal-magnetic tripping, and a breaking capacity of 10 kA meeting IS/IEC 60898-1 standards.

Key Specifications

• Poles: Four Pole (4P)

• Current Rating: 40 Amperes

• Curve Type: C-Curve (trips at 5-10 times rated current, suitable for moderate motor and lighting inrush)

• Rated Voltage: 415V AC

• Frequency: 50 Hz

• Breaking Capacity: 10 kA

• Dimensions: 8 x 8 x 10 cm

• Weight: 0.4 kg

• Mounting: DIN rail with bi-stable clip

• Terminal Capacity: Supports cables up to 35 mm² (aluminum/copper), combi-head screws with 2 Nm torque

• Protection Class: IP20

Features

• Positive contact indication (red ON/green OFF)

• 12-plate arc chamber for rapid arc quenching

• Air circulation grooves for improved thermal management

• Finger-proof shrouded terminals for safety

• Energy Limiting Class 3 design for fast fault clearance

• Easy installation and removal with a bi-stable DIN clip

This MCB from Selvo Electricals combines safety, reliability, and durability in a compact and efficient design for versatile electrical protection needs.
