Selvo 20A C Curve Double Pole MCB, GSELDPC12020, (Pack of 12)

The Selvo 20A C-Curve Double Pole MCB, model GSELDPC12020, available in a pack of 12, delivers reliable overload and short-circuit protection for two-phase circuits in residential, commercial, and light industrial settings. It incorporates thermal-magnetic tripping with a flame-retardant PBT body and IS/IEC 60898-1 certification for consistent safety.

Key Specifications

• Poles: Double Pole (2P)

• Rated Current: 20 Amperes

• Curve Type: C-Curve (trips at 5-10 times rated current for moderate inrush from motors/lighting)

• Rated Voltage: 240/415V AC

• Frequency: 50 Hz

• Breaking Capacity: 10 kA

• Dimensions: Approx. 8 x 4 x 10 cm; Weight: 0.2 kg

• Mounting: DIN rail with bi-stable clip

• Terminal Capacity: Up to 35 mm² (aluminum/copper), combi-head screws (2 Nm torque)

• Protection Class: IP20

Features

• Positive contact indication (red ON/green OFF)

• High-speed arc quenching via 12-plate chamber (3-5 ms response)

• Air circulation grooves for thermal management; energy limiting Class 3

• Shrouded finger-proof terminals and silver graphite contacts for durability

This economical MCB from Selvo Electricals supports straightforward installation and robust circuit safeguarding.
