Selvo 16A C Curve Single Pole MCB, GSELSPC12003, (Pack of 12)

The Selvo 16A C-Curve Single Pole MCB, model GSELSPC12003, available in a pack of 12, offers reliable overload and short-circuit protection for residential and commercial circuits. It uses thermal-magnetic technology with a flame-retardant PBT body for durability and safety.

Key Specifications

• Poles: Single Pole (1P)

• Rated Current: 16 Amperes

• Curve Type: C-Curve (trips at 5-10 times rated current for moderate inrush loads like lighting/small motors)

• Rated Voltage: 240V AC

• Frequency: 50 Hz

• Breaking Capacity: 10 kA

• Dimensions: 7 x 2 x 9 cm; Weight: 0.1 kg

• Mounting: DIN rail with bi-stable clip

• Terminal Capacity: Up to 35 mm² (aluminum/copper), combi-head screws (2 Nm torque)

• Standards: IS/IEC 60898-1 compliant

Features

• Positive contact indication (red ON/green OFF)

• IP20 finger-proof protection with shrouded terminals

• High-speed arc quenching (12-plate chamber, 3-5 ms response)

• Air circulation grooves for cooler operation; energy limiting Class 3

This cost-effective MCB from Selvo Electricals ensures easy installation and long-term performance.
