Selvo 10A C Curve Single Pole MCB, GSELSPC12002, (Pack of 12)

The Selvo 10A C-Curve Single Pole MCB, model GSELSPC12002, available in a pack of 12, provides reliable overload and short-circuit protection for electrical circuits. It features a flame-retardant PBT body for enhanced insulation and strength, suitable for residential and commercial use.

Key Specifications

• Poles: Single Pole (1P)

• Rated Current: 10 Amperes

• Curve Type: C-Curve (handles moderate inrush currents from lighting and small motors)

• Rated Voltage: 240V AC

• Frequency: 50 Hz

• Breaking Capacity: Up to 10 kA (per Selvo series standards)

• Mounting: DIN rail with bi-stable clip

• Terminal Capacity: Large dual terminals up to 35 mm² (aluminum or copper)

• Standards: IS/IEC 60898-1 certified

Features

• Positive contact indication (red ON/green OFF)

• Air circulation grooves for cooler operation

• IP20 protection degree with finger-proof terminals

• High-speed arc quenching (12-plate arc chamber)

• Energy limiting Class 3 for rapid fault interruption

This cost-effective MCB from Selvo Electricals ensures safe, durable performance with easy installation.
