Schneider Electric Acti9 xC60 25A C-Curve Three Pole MCB, A9N3P25C, Breaking Capacity: 10 kA, (Pack of 6)

The Schneider Electric Acti9 xC60 25A C-Curve Three Pole MCB, model A9N3P25C, with a breaking capacity of 10 kA, is available in a pack of 6. Its key specifications and features are:

• Poles: Three Pole (3P)

• Current Rating: 25 Amperes

• Rated Voltage: 240V AC, 50/60 Hz

• Breaking Capacity: 10 kA at 415V AC, compliant with EN/IEC 60898-1 and EN/IEC 60947-2 standards

• Curve Type: C-Curve, designed for moderate inrush currents typically from motor and lighting loads

• Terminal Capacity: Tunnel-type terminals supporting up to 16 mm² flexible and 25 mm² rigid wires; Biconnect terminals on top

• Mounting: Clip-on 35 mm DIN rail, modular width 54 mm, height 85 mm, depth 77.5 mm

• Mechanical & Electrical Durability: Rated for 20,000 mechanical and electrical operations

• Features: Positive contact indication (ON/OFF), reversible line-load installation, energy limitation Class 3, fast closure mechanism, compatibility with Schneider Acti9 auxiliaries for advanced monitoring and protection

• Protection Class: IP20

• Insulation Voltage: 500V AC

• Impulse Withstand Voltage: 6 kV

• Operating Temperature: -30°C to 70°C

• Suitable Applications: Reliable overload and short circuit protection in three-phase residential, commercial, and industrial systems

This MCB delivers reliable, safe, and energy-efficient circuit protection with Schneider Electric's high-quality modular design, trusted for diverse electrical protection applications
