Schneider Electric Acti9 xC60 25A C-Curve Single Pole MCB, A9N1P25C, Breaking Capacity: 10 kA, (Pack of 12)

The Schneider Electric Acti9 xC60 25A C-Curve Single Pole MCB, model A9N1P25C, with a breaking capacity of 10 kA, is available in a pack of 12. Its key features and specifications are:

• Poles: Single Pole (1P)

• Current Rating: 25 Amperes

• Breaking Capacity: 10 kA at 230/240V AC (IS/IEC 60898-1 compliant)

• Curve Type: C-Curve, designed for circuit protection with moderate inrush currents such as lighting and motor loads

• Rated Voltage: 220–240V AC, 50/60 Hz

• Insulation Voltage: 500V AC

• Impulse Withstand Voltage: 6 kV

• Terminal Capacity: Tunnel-type terminals accepting up to 16mm² flexible and 25mm² rigid wires; Biconnect terminals on top

• Mounting: Clip-on 35mm DIN rail; modular width 18mm, height 85mm, depth 77.5mm

• Mechanical & Electrical Durability: 20,000 operations mechanical, 10,000 electrical

• Features: Positive contact indication for operational safety, energy limitation class 3, reversible line-load mounting for flexibility, fast closure mechanism, compatibility with Schneider Acti9 auxiliary devices for enhanced protection and remote monitoring

• Applications: Suitable for residential, commercial, and industrial electrical protection with easy panel integration and reliable performance

This model provides efficient, safe, and compliant circuit protection in a compact, modular design from Schneider Electric, trusted for quality and durability.
