Schneider Electric Acti9 xC60 20A C-Curve Three Pole MCB, A9N3P20C, Breaking Capacity: 10 kA, (Pack of 6)

The Schneider Electric Acti9 xC60 20A C-Curve Three Pole MCB, model A9N3P20C, with a breaking capacity of 10 kA, comes in a pack of 6. Key specifications and features include:

• Poles: Three Pole (3P)

• Current Rating: 20 Amperes

• Rated Voltage: 240V AC, 50/60 Hz

• Breaking Capacity: 10 kA at 415V AC, compliant with EN/IEC 60898-1 and EN/IEC 60947-2

• Curve Type: C-Curve, suitable for moderate inrush currents typical in motor and lighting circuits

• Terminal Capacity: Tunnel-type terminals support up to 16mm² flexible and 25mm² rigid wires, with Biconnect terminals on top

• Mounting: Clip-on 35 mm DIN rail, modular width 54 mm, height 85 mm, depth 77.5 mm

• Mechanical & Electrical Durability: Rated for 20,000 operations

• Features: Positive contact indication (ON/OFF), reversible line-load installation, energy limitation Class 3, fast closure mechanism, and compatibility with Schneider Acti9 auxiliaries for advanced monitoring and protection

• Protection Class: IP20

• Insulation Voltage: 500V AC

• Impulse Withstand Voltage: 6 kV

• Operating Temperature: -30°C to 70°C

• Applications: Provides reliable overload and short circuit protection in three-phase residential, commercial, and industrial electrical systems

This MCB combines safety, reliability, and efficiency with a compact modular design from Schneider Electric, ensuring durable and compliant circuit protection.
