Schneider Electric Acti9 xC60 1A C-Curve Three Pole MCB, A9N3P01C, Breaking Capacity: 10 kA, (Pack of 6)

The Schneider Electric Acti9 xC60 1A C-Curve Three Pole MCB, model A9N3P01C, with a breaking capacity of 10 kA, is supplied in a pack of 6 units. Its key specifications and features include:

• Poles: Three Pole (3P)

• Current Rating: 1 Ampere

• Rated Voltage: 240V AC, 50/60 Hz (suitable for 380-415V AC three-phase systems)

• Breaking Capacity: 10 kA at 415V AC, compliant with EN/IEC 60898-1 and EN/IEC 60947-2 standards

• Curve Type: C-Curve, designed for moderate inrush currents common in lighting and motor circuits

• Terminal Capacity: Tunnel-type terminals supporting up to 16 mm² flexible and 25 mm² rigid wires, Biconnect terminals on top

• Mounting: Clip-on 35 mm DIN rail mounting, dimensions approx. Width 54 mm × Height 85 mm × Depth 77.5 mm

• Mechanical and Electrical Durability: 20,000 operations each

• Features: Positive contact indication (ON/OFF), reversible line-load connection, fast closure mechanism, energy limitation Class 3, suitable for isolation, compatible with Schneider Acti9 auxiliaries for advanced monitoring and protection

• Insulation Voltage: 500V AC

• Impulse Withstand Voltage: 6 kV

• Protection Class: IP20

• Operating Temperature: -30°C to 70°C

• Application: Reliable protection against overload and short circuits in residential, commercial, and industrial electrical distribution panels

This MCB is engineered for high safety, reliability, and efficiency in modular compact design, trusted under the Schneider Electric brand for comprehensive electrical protection.
