Schneider Electric Acti9 xC60 1A C-Curve Single Pole MCB, A9N1P01C, Breaking Capacity: 10 kA (Pack of 12)

The Schneider Electric Acti9 xC60 1A C-Curve Single Pole MCB, A9N1P01C, is a high-performance miniature circuit breaker designed for overload and short-circuit protection in residential, commercial, and industrial applications. Here are the key details:

• Poles: Single Pole (1P)

• Rated Current: 1A

• Curve Type: C-Curve (moderate inrush tolerance)

• Breaking Capacity: 10 kA at 230/240V AC (IS/IEC 60898-1)

• Rated Voltage: 220–240V AC, 50/60Hz

• Operating Voltage: 220–240V AC, 12–48V DC, 60V DC

• Insulation Voltage: 500V AC (Ui)

• Impulse Withstand Voltage: 4kV

• Terminal Capacity: 16mm² flexible/25mm² rigid wire (bottom), Biconnect terminal (top)

• Mounting: 35mm DIN rail, modular width 18mm, height 85mm, depth 77.5mm

• Mechanical & Electrical Durability: 20,000 operations

• Standards: IS/IEC 60898-1, EN/IEC 60947-2

• Additional Features: Suitable for isolation, ON/OFF indicator, field-fittable auxiliaries, serrated terminals, positive contact indication, Class 3 energy limitation, and compatibility with Schneider Acti 9 system add-ons

This pack includes 12 pieces, each providing robust circuit protection and easy integration into various panels, with a compact, reliable, and high-performance design
