Schneider Electric Acti9 xC60 1A C-Curve Double Pole MCB, A9N2P01C, Breaking Capacity: 10 kA, (Pack of 6)

The Schneider Electric Acti9 xC60 1A C-Curve Double Pole MCB, model A9N2P01C, with a breaking capacity of 10 kA, comes as a pack of 6. Key specifications are:

• Poles: Double Pole (2P)

• Rated Current: 1 Ampere

• Rated Voltage: 220-240V AC

• Breaking Capacity: 10 kA at 230/240V AC (IS/IEC 60898-1 compliant)

• Curve Type: C-Curve (designed for moderate inrush currents such as lighting and motor loads)

• Terminal Capacity: Tunnel terminals at bottom support up to 16mm² flexible and 25mm² rigid wires; Biconnect terminals on top

• Mounting: Clip-on 35mm DIN rail, width 36mm, height 85mm, depth 77.5mm

• Mechanical and Electrical Durability: 20,000 operations

• Features: Positive contact indication for assurance of disconnection, energy limitation class 3, reversible line-load installation, fast closure mechanism, compatible with Schneider Acti9 field-fit auxiliaries for enhanced monitoring and protection

• Insulation Voltage: 500V AC

• Impulse Withstand Voltage: 6 kV

• Operational Frequency: 50/60 Hz

• Ambient Operating Temperature: -30°C to +70°C

• Protection Class: IP20

This MCB model is engineered for reliable, safe, and flexible electrical protection with easy panel integration and Schneider Electric's quality assurance suitable for a wide range of residential, commercial, and industrial applications.
