Schneider Electric Acti9 xC60 16A C-Curve Single Pole MCB, A9N1P16C, Breaking Capacity: 10 kA, (Pack of 12)

The Schneider Electric Acti9 xC60 16A C-Curve Single Pole MCB, model A9N1P16C, with a breaking capacity of 10 kA, comes as a pack of 12 units. Key specifications include:

• Poles: Single Pole (1P)

• Rated Current: 16 Amperes

• Breaking Capacity: 10 kA at 230/240V AC, compliant with IS/IEC 60898-1

• Curve Type: C-Curve for handling moderate inrush currents such as lighting and motor circuits

• Rated Voltage: 220–240V AC, 50/60 Hz

• Insulation Voltage: 500V AC

• Impulse Withstand Voltage: 6 kV

• Terminal Capacity: Tunnel-type terminals supporting 16mm² flexible and 25mm² rigid wires, Biconnect terminals on top

• Mounting: Clip-on 35mm DIN rail, modular width 18mm, height 85mm, depth 77.5mm

• Mechanical & Electrical Durability: 20,000 operations

• Features: Positive contact indication (ON/OFF), energy limitation class 3, reversible line-load mounting, fast closure mechanism, and compatibility with Schneider Acti9 field-fit auxiliaries for enhanced monitoring and protection

• Standards: Certified per IS/IEC 60898-1 and EN/IEC 60947-2

• Applications: Provides reliable electrical overload and short circuit protection for residential, commercial, and industrial applications with easy integration in distribution panels

This Schneider Electric MCB model is engineered for reliability, safety, and efficiency, suitable for a wide range of electrical protection needs.
