Schneider Electric Acti9 xC60 10A C-Curve Three Pole MCB, A9N3P10C, Breaking Capacity: 10 kA, (Pack of 6)

The Schneider Electric Acti9 xC60 10A C-Curve Three Pole MCB, model A9N3P10C, with a breaking capacity of 10 kA, is available in a pack of 6 units. Key specifications and features include:

• Poles: Three Pole (3P)

• Current Rating: 10 Amperes

• Breaking Capacity: 10 kA at 240/415V AC (IS/IEC 60898-1 and EN/IEC 60947-2 compliant)

• Curve Type: C-Curve, for moderate inrush currents such as lighting and motor loads

• Terminal Capacity: Tunnel-type terminals allowing up to 16mm² flexible and 25mm² rigid wire, Biconnect terminals on top

• Mounting: Clip-on 35mm DIN rail, modular width 54mm, height 85mm, depth 77.5mm

• Mechanical & Electrical Durability: 20,000 operations each

• Insulation Voltage: 500V AC

• Impulse Withstand Voltage: 6 kV

• Protection Class: IP20

• Operating Temperature: -30°C to +70°C

• Features: Positive contact indication (ON/OFF), energy limitation Class 3, reversible line-load, fast closure, suitable for DC applications up to 60V per pole, can be equipped with Schneider Acti9 auxiliaries (monitoring, RCD, remote control)

• Applications: Overload and short-circuit protection for three-phase systems in residential, commercial, and industrial use

This MCB provides reliable, safe, and efficient circuit protection in a high-quality modular design from Schneider Electric.
