RR RATNA CAT 6 (UTP) PVC LAN CABALES

RR RATNA CAT 6 (UTP) PVC LAN CABALES

Regular price Rs. 2,953.36
Regular price Rs. 5,092.00 Sale price Rs. 2,953.36
Sale Sold out
Length
Quantity
RR RATNA CAT 6 (UTP) PVC LAN Cables are enhanced unshielded twisted pair cables designed for high-speed data communication networks.

Key specifications:

  • Cable Type: CAT 6 UTP (Unshielded Twisted Pair)

  • Conductor: Solid bare copper, 24 AWG (approx. 0.5 mm diameter)

  • Insulation: High-density polyethylene (HDPE)

  • Pair Configuration: 4 twisted pairs (8 conductors total)

  • Outer Jacket: Flame retardant (FR) PVC, typically grey color

  • Data Rate Support: 100+ Mbps, supporting Gigabit Ethernet standards up to 250 MHz bandwidth

  • Standards Compliance: Exceeds EN 50173, ISO/IEC 11801, and TIA/EIA 568-B-1/B-2

  • Mechanical Properties: Max tensile load 10 kg during installation, minimum bend radius 8 times outer diameter during installation, 4 times during operation

  • Temperature Rating: Installation 0°C to +50°C, operation -10°C to +60°C

  • Electrical Properties: Low conductor resistance, dielectric strength 1 kV DC for 1 minute, insulation resistance >500 MΩ/km, low capacitance unbalance

  • Packaging: Available typically in 305 meter rolls
