RR FLAMEX HRFR 1.50 Sqmm Industrial Cable 1100V (90 MTR)

The RR FLAMEX HRFR 1.50 Sqmm Industrial Cable 1100V (90 MTR) is a heat resistant and flame retardant single core copper cable suitable for fixed wiring in industrial, commercial, and residential buildings that require enhanced fire safety.

Key Specifications

• Conductor: Multi-stranded electrolytic copper, typically 30 strands of 0.26 mm diameter, Class 2 conductor as per IS 8130 for flexibility and conductivity.

• Core Size: 1.50 Sqmm single core.

• Insulation: High-grade Heat Resistant and Flame Retardant (HRFR) PVC insulation, engineered for elevated temperature tolerance and flame retardant properties. Conforms to IS 5831 Type C – HR 85°C + FR.

• Voltage Rating: Up to and including 1100V AC.

• Insulation Thickness: Approximately 0.6 mm.

• Overall Diameter: Approximately 2.8 mm.

• Maximum DC Conductor Resistance: Around 13.3 Ω/km.

• Current Carrying Capacity: About 18A (casing wiring) and 16A (concealed wiring).

• Cable Length: Supplied in 90-meter coils.

• Colors: Available in multiple colors including green, red, yellow, black, blue, grey, and white.

• Certifications: IS 649 marked, FIA/TAC approved, RoHS and REACH compliant.
