RR FLAMEX HRFR 1.00 Sqmm Industrial Cable 1100V (90 MTR)

The RR FLAMEX HRFR 1.00 Sqmm Industrial Cable 1100V (90 MTR) is a heat resistant and flame retardant single core copper cable suitable for fixed wiring in industrial, commercial, and residential buildings requiring enhanced fire safety.

Key Specifications

• Conductor: Multi-stranded electrolytic copper, typically 32 strands of 0.21 mm diameter, Class 2 conductor as per IS 8130 for flexibility and conductivity.

• Core Size: 1.00 Sqmm single core.

• Insulation: High-grade Heat Resistant and Flame Retardant (HRFR) PVC insulation engineered to withstand elevated temperatures and retard flame propagation, conforming to IS 5831 Type C – HR 85°C + FR.

• Voltage Rating: Up to and including 1100V AC.

• Insulation Thickness: Approximately 0.6 mm.

• Overall Diameter: Approx. 2.6 mm.

• Max DC Conductor Resistance: Around 19.5 Ω/km at 20°C.

• Current Carrying Capacity: About 14A for casing wiring and 13A for concealed wiring.

• Cable Length: 90 meters per coil.

• Color Options: Available in green, black, blue, red, yellow, grey, white.

• Certifications: IS 694 marked, FIA/TAC approved, REACH and RoHS compliant.
