RR FLAMEX HRFR 0.75 Sqmm Industrial Cable 1100V (90 MTR)

The RR FLAMEX HRFR 0.75 Sqmm Industrial Cable 1100V (90 MTR) is a heat resistant and flame retardant single core copper cable designed for fixed wiring in residential, commercial, and industrial buildings where enhanced fire safety is required.

Key Specifications

• Conductor: Thin strands of electrolytic copper, multi-drawn for uniform resistance, dimension, and flexibility, typically 24 strands of 0.21 mm diameter for 0.75 Sqmm size.

• Core Size: 0.75 Sqmm single core cable.

• Insulation: High-grade Heat Resistant and Flame Retardant (HRFR) PVC insulation engineered to withstand elevated temperatures while effectively retarding flame propagation. It conforms to IS 5831 Type C – HR 85°C + FR.

• Voltage Rating: Up to and including 1100V AC.

• Insulation Thickness: Approximately 0.6 mm.

• Overall Diameter: Approx. 2.3 mm.

• Max DC Conductor Resistance: Around 26 Ω/km at 20°C.

• Current Carrying Capacity: About 9-10A (depending on installation method, casing or concealed).

• Cable Length: Supplied in coils of 90 meters, packed in protective cartons.

• Colors: Available in multiple colors including green, black, red, blue, yellow, grey, white.

• Certifications: IS 649 marked, FIA/TAC approved, CPC (Construction Products Certification) compatible, REACH and RoHS compliant.
