RR EBXL 0.75 Sqmm HFFR Single Core Copper Industrial Cable (90 Mtr)

The RR EBXL 0.75 Sqmm HFFR Single Core Copper Industrial Cable (90 Mtr) is a premium building and industrial wire emphasizing fire safety, reliability, and environmental protection. It is designed for installations where halogen-free flame retardance and superior mechanical/electrical properties are critical.

Key Specifications

• Conductor: Multistrand, electrolytic grade, annealed copper for optimal flexibility and conductivity — typically 24 fine strands per core.

• Core Size: 0.75 Sqmm single core (suitable for control, lighting, or industrial wiring).

• Cable Length: 90 meters per coil, convenient for standard industrial site installations.

• Insulation: HFFR (Halogen-Free Flame Retardant) E-Beam cross-linked polymer (HFI-XL), minimizing toxic emissions in fire scenarios, complying with international LSOH (Low Smoke Zero Halogen) standards.

• Insulation Thickness: Typically around 0.6 mm for 0.75 Sqmm conductors.

• Voltage Rating: 1100V (suitable for power and control circuits).

• Current Carrying Capacity: About 9A in conduit, up to 14A when clipped directly.

• Temperature Range: -25°C to +110°C operational; short circuit ratings up to 300°C insulation temp.

• Conductor Resistance: Maximum ~26 Ω/km at 20°C for typical flexible models.

• Compliance: IS 17048 marked, RR Kabel LS0H/EBXL standards; often FIA/TAC approved.
