RR 10.0 Sqmm (140/0.3) 3 Core Submersible Flat Cable 1100V (50 MTR)

The RR 10.0 Sqmm (140/0.3) 3 Core Submersible Flat Cable 1100V (50 MTR) is a high-quality cable designed for submersible pump connections, ensuring durability, water resistance, and electrical safety in demanding environments.

Key Specifications

• Conductor: Electrolytic annealed plain copper with 140 strands of 0.3 mm diameter, class 2 conductor (IS 8130).

• Core Count and Colors: 3 cores colored red, yellow (center core), and blue.

• Insulation and Sheath: XLPE insulation with PVC ST-2 sheath, black with knurling on width sides for abrasion resistance as per IS 5831.

• Voltage Rating: Up to and including 1100V AC.

• Nominal Insulation Thickness: 1.0 mm.

• Nominal Sheath Thickness: 1.4 mm.

• Overall Dimensions: 24.2 mm (width) × 10.4 mm (height) ±0.5 mm.

• Maximum DC Resistance: 1.91 Ω/km at 20°C.

• Current Carrying Capacity: 48 A.

• Maximum Operating Temperature: 90°C.

• Test Voltage: 3 kV for 5 minutes.

• Length: 50 meters per coil.

• Certifications: IS 694, FIA/TAC, REACH, RoHS, CE compliant.
