RR 10.0 Sqmm (140/0.3) 3 Core Submersible Flat Cable 1100V (100 MTR)

The RR 10.0 Sqmm (140/0.3) 3 Core Submersible Flat Cable 1100V (100 MTR) is a robust cable specially designed for connecting submersible pumps, ensuring high electrical safety, durability, and resistance to harsh environmental conditions.

Key Specifications

• Conductor: Electrolytic annealed copper with 140 strands of 0.3 mm diameter, conforming to Class 2 standard for flexibility and conductivity.

• Core Count and Colors: 3 cores, color-coded red, yellow (center core), and blue.

• Insulation and Sheath: XLPE insulation with PVC ST-2 outer sheath, black in color with knurling on width for abrasion resistance.

• Voltage Rating: Suitable up to and including 1100V AC.

• Nominal Insulation Thickness: 1.0 mm.

• Sheath Thickness: 1.4 mm.

• Overall Dimensions: Approximately 24.2 mm width × 10.4 mm height (+/- 0.5 mm tolerance).

• Maximum DC Resistance: Approximately 1.91 Ω/km at 20°C.

• Current Carrying Capacity: Approximately 48 A.

• Temperature: Maximum operating temperature 90°C; with test voltage 3 kV for 5 minutes.

• Length: Standard length of 100 meters per coil.

• Certifications: IS 694 marked, FIA/TAC approved, REACH, RoHS, CE certified.
