L&T Tripper 40A C-Curve Single Pole MCB, BA10400C

The L&T Tripper 40A C-Curve Single Pole MCB, model BA10400C, has the following specifications:

• Current Rating: 40 Amperes

• Poles: Single Pole (1P)

• Voltage Rating: 240/415V AC

• Breaking Capacity: 6 kA

• Curve Type: C-Curve, designed for moderate inrush current applications like lighting and motor circuits

• Terminal Capacity: Supports cables up to 35 sqmm

• Compliance: IS/IEC 60898-1 standards

• Frequency: 50/60 Hz

• Features: Heavy-duty contacts for extended service life, fire retardant casing, true contact indication, energy-saving design with reduced watt loss, cooler operation due to breathing spaces around the pole

• Dimensions: Approximately 74.5 mm (L) × 17.5 mm (W) × 87.3 mm (H)

• Applications: Ideal for overload and short circuit protection in residential, commercial, and industrial lighting and power circuits

This MCB provides reliable and efficient protection with a compact and durable design, suitable for a wide range of electrical installations by L&T, a trusted manufacturer.
