L&T Tripper 25A C-Curve Single Pole MCB, BA10250C

The L&T Tripper 25A C-Curve Single Pole MCB, model BA10250C, is a high-quality miniature circuit breaker designed for overcurrent and short-circuit protection. Here are its key specifications:

• Rated Current: 25 Amperes

• Curve Type: C-Curve, suitable for moderate inrush currents like lighting and motor circuits

• Poles: Single Pole (1P)

• Voltage Rating: 240/415V AC

• Breaking Capacity: 6 kA

• Terminal Capacity: Supports cable sizes up to 35 sqmm

• Standards: Compliant with IS/IEC 60898-1, ISI certified

• Frequency: 50/60 Hz

• Dimensions: Approximately 74.5 mm (L) × 17.5 mm (W) × 87.3 mm (H)

• Weight: ~140 g

• Features: Heavy-duty contacts for longer life, fire retardant casing, true contact indication, innovative breathing channels for cooler operation, energy-saving design with approx. 50% lower watt loss than IEC standards

• Manufacturer: L&T Electrical & Automation, Mumbai, India

This MCB is ideal for residential, commercial, and industrial electrical installations requiring secure and reliable circuit protection with enhanced safety and durability.
