L&T Tripper 16A C-Curve Double Pole MCB, BA20160C

The L&T Tripper 16A C-Curve Double Pole MCB, model BA20160C, is designed to provide reliable circuit protection for residential, commercial, and light industrial applications. Here are its key specifications:

• Poles: Double Pole (2P)

• Current Rating: 16 Amperes

• Voltage Rating: 230/415V AC

• Breaking Capacity: 6 kA

• Tripping Curve: C-Curve (for moderate inrush currents typical of lighting and motor circuits)

• Terminal Capacity: Supports cables up to 35 sqmm

• Standards: IS/IEC 60898-1 certified, ISI marked

• Features: Heavy-duty contacts for longer operational life, fire-retardant plastic casing, innovative breathing channels between poles for cooling to reduce thermal stress, energy-efficient design with significantly reduced watt loss, and true contact indication

• Dimensions: Approx. 74.5 mm (L) × 17.5 mm (W) × 87.3 mm (H)

• Applications: Effective overload and short-circuit protection in electrical circuits, with easy installation in distribution boards and panels

This MCB ensures robust electrical safety and durability while complying with international standards, making it a trusted choice from Larsen & Toubro Limited (L&T).
