L&T Tripper 10A C-Curve Single Pole MCB, BA10100C

The L&T Tripper 10A C-Curve Single Pole MCB, model BA10100C, is a modular miniature circuit breaker designed for circuit protection in residential and commercial applications. Here are the key technical specifications:

• Current Rating: 10 Amps

• Curve Type: C-curve (suitable for general power and lighting loads; handles moderate inrush currents)

• Poles: Single Pole (SP)

• Voltage Rating: 240/415V AC

• Breaking Capacity: 6 kA

• Frequency: 50/60 Hz

• Terminal Capacity: Up to 35 sqmm cable

• Conformance Standards: IS/IEC 60898-1, EN/IEC 60898-1

• Warranty: 18 months

• Dimensions: 74.5 mm (L) × 17.5 mm (W) × 87.3 mm (H)

• Weight: Approx. 132 g

• Design Features: Heavy-duty contacts, fire-retardant body, energy-efficient construction, breathing channels for cooler operation, true contact indication

This MCB provides reliable overload and short-circuit protection for lighting and small power circuits, making it a preferred choice for distribution boards in domestic and small commercial setups.
