L&T Tripper 10A C-Curve Double Pole MCB, BA20100C

The L&T Tripper 10A C-Curve Double Pole MCB, model BA20100C, is designed for reliable protection of electrical circuits in residential and commercial applications. The main specifications are:

• Poles: Double Pole (2P)

• Current Rating: 10 Amperes

• Voltage Rating: 230/415V AC

• Breaking Capacity: 6 kA

• Tripping Curve: C-Curve (suitable for moderate inrush currents from lighting and motor loads)

• Terminal Capacity: Supports cable sizes up to 35 sqmm

• Standards Compliance: IS/IEC 60898-1, ISI certified

• Frequency: 50/60 Hz

• Features: Heavy-duty contacts for durability, fire-retardant casing for safety, energy-efficient design with around 50% lower watt loss compared to IEC standards, true contact indication, and efficient cooling via breathing channels for longer product life

• Suitable for: Overload and short circuit protection in electrical distribution boards for domestic, commercial, and light industrial use

This MCB is part of the trusted L&T Tripper series, known for robust safety features and high performance in circuit protection.
