KEI CAT- 6 4 PAIR UNSHIELDED TWISTED PAIR ( UPT ) LAN CABLES

KEI CAT-6 4 Pair Unshielded Twisted Pair (UTP) LAN Cable is a high-quality cable designed for local area network (LAN) and structured cabling systems with the following specifications and features:

• Conductor: Solid bare electrolytic grade copper conductor, 23 AWG (approximately 0.57 mm diameter).

• Pairs: 4 twisted pairs in the cable.

• Insulation: High-density polyethylene (HDPE) insulation around each conductor for excellent electrical performance.

• Separator: Central spline separator made of polyethylene to keep pairs separated and reduce crosstalk.

• Jacket: Outer PVC jacket available in colors like yellow, dark grey, and blue, with customized colors also available.

• Cable Diameter: Approximately 6.0 mm.

• Standards: Meets ANSI/TIA-568-C.2 standard requirements and supports Gigabit Ethernet (1000Base-T).

• Electrical Performance:

  • DC Resistance: Max 9.38 Ω/100m

  • Capacitance: Max 330 pF/100m

  • Impedance: 100 ± 15 Ω

  • Supports high-speed data transmission and improves crosstalk performance due to the central spline and cable design.

• Packing: Typically supplied in 305-meter pans.
