KEI 6.0 sqmm Copper PVC Sheathed XLPE Low Tension 2XY Un-Armoured Power Cable, ( 1 METER )

The KEI 6.0 sqmm Copper PVC Sheathed XLPE Low Tension Un-Armoured Power Cable (per meter) is designed for reliable power transmission in low tension applications where armouring is not required.

Key Specifications

• Conductor Material: High-conductivity copper.

• Cross Sectional Area: 6.0 sqmm.

• Core Options: Commonly available in , 2 core, 3 core, 4 core; 4 core is preferred for three-phase with neutral cabling.

• Insulation: XLPE (Cross-linked Polyethylene), offering superior thermal and electrical insulation.

• Sheath: PVC (Polyvinyl Chloride) for added protection.

• Armouring: Un-armoured design (no steel strip/wire)—used for applications where mechanical protection from armouring is not needed.

• Voltage Grade: 1100 Volts (Low Tension).

• Nominal Diameter: Approx. 17.5 mm for 4 core variant.

• Nominal Insulation Thickness: 1.0 mm.

• Nominal Outer Sheath Thickness: 1.40 mm.

• Net Weight: Approx. 771 kg/km for 4 core 6 sqmm cable.

• Max DC Resistance @ 20°C: 4.6 Ohms/km.

• Max AC Resistance @ 70°C: 5.52 Ohms/km.

• Current Rating: Typically up to 25-32 Amps depending on installation and ambient temperature.
