KEI 500.0 sqmm Copper PVC Sheathed XLPE Low Tension 2XY Un-Armoured Power Cable, ( 1 METER )

The KEI 500.0 sqmm Copper PVC Sheathed XLPE Low Tension 2XY Un-Armoured Power Cable (per meter) specifications are:

• Conductor Material: Copper (high conductivity)

• Cross Sectional Area: 500 sqmm

• Type: 2XY (Unarmoured, XLPE insulated, PVC sheathed)

• Number of Cores: Usually 2 or 4 cores

• Insulation Thickness: Approx. 2.00 mm nominal XLPE

• PVC Inner Sheath Thickness: Around 0.7 mm nominal

• PVC Outer Sheath Thickness: About 2.8 mm nominal

• Overall Diameter: Roughly 63.5 mm nominal (4 core)

• Max DC Resistance @ 20°C: Approx. 0.066 Ohms/km

• Current Rating: Approx. 520 Amps direct in ground, higher in air

• Approximate Weight: Around 12000 to 14000 kg per km nominal

• Voltage Rating: 1100 V Low Tension as per IS 7098 (Part 1): 1988

• Standard Compliance: IS 7098 (Part 1): 1988
