KEI 185.0 sqmm Copper PVC Sheathed XLPE Low Tension 2XY Un-Armoured Power Cable, ( 1 METER )

KEI 185.0 sqmm Copper PVC Sheathed XLPE Low Tension 2XY Un-Armoured Power Cable, ( 1 METER )

Rs. 0.00
Rs. 0.00
Sale Sold out
Size
The KEI 185.0 sqmm Copper PVC Sheathed XLPE Low Tension 2XY Un-Armoured Power Cable (per meter) has these specifications:

  • Conductor Material: Copper, high conductivity

  • Cross Sectional Area: 185 sqmm

  • Type: 2XY (Un-armoured, XLPE insulated, PVC sheathed)

  • Number of Cores: Usually available in 2 or 4 cores configurations

  • Insulation Thickness: Approx. 1.6 mm XLPE

  • PVC Sheath Thickness: Around 2.04 mm nominal outer sheath

  • Overall Diameter: Approximately 46 to 49 mm (depending on number of cores and construction)

  • Max DC Resistance @ 20°C: Approx. 0.099 Ohms/km

  • Current Rating: Around 330 to 340 Amps

  • Net Cable Weight: Approx. 6200 to 7300 kg/km

  • Voltage Rating: 1100 V Low Tension

  • Standards: IS 7098 (Part 1): 1988 compliant
