Havells 50.0 Sqmm Multicore Black PVC Insulated Copper Conductor Round Flexible Industrial Cable, ( 100MTR)

The Havells 50.0 Sqmm Multicore Black PVC Insulated Copper Conductor Round Flexible Industrial Cable (100 MTR) is a heavy-duty, high-performance industrial cable designed to carry large electrical loads safely and efficiently. It conforms to IS:694 standards and is rated for 1100 V systems, making it suitable for demanding electrical power and control applications in industrial environments.

Key Specifications:

• Brand: Havells India Ltd.

• Conductor Material: Annealed bare copper, Class 5 flexibility according to IS:8130

• Cross Section: 50.0 sq. mm

• Number of Cores: Available commonly in 3-core and 4-core configurations

• Voltage Rating: 1100 V

• Insulation: Flame retardant PVC Type D as per IS:5831

• Outer Sheath: Black PVC Type ST-3, round, abrasion and heat resistant

• Insulation Thickness: Approximately 1.0 mm

• Conductor Resistance (Max at 20°C): Approx. 0.395 Ω/km

• Current Carrying Capacity: Around 181 A depending on installation conditions

• Overall Diameter: About 29.5 mm

• Temperature Rating: Continuous operation up to 70°C
