Havells 120.0 sqmm Copper PVC Sheathed XLPE Low Tension Armoured Power Cable, A2XWY/A2XFY ( 1 METER )

Rs. 2,303.70

~~Rs. 5,485.00~~ Rs. 2,303.70

Rs. 230,370.00/100m

Sale Sold out

Core 1 core 2 core 3 core 3.5 core 4 core

The Havells 120.0 sqmm Copper PVC Sheathed XLPE Low Tension Armoured Power Cable, A2XWY/A2XFY (1 Meter) is a heavy-duty, 1.1 kV rated LT cable engineered for industrial, utility, and commercial power distribution. It combines high current-carrying capacity with superior insulation, fire safety, and mechanical protection, conforming to IS 7098 (Part 1):1988 and IEC 60502-1 standards.

Technical Specifications

Parameter	Details
Brand	Havells
Product Type	LT Copper Armoured Power Cable
Model Code	A2XWY (Round Wire Armoured) / A2XFY (Flat Strip Armoured)
Conductor Material	High-conductivity Annealed Copper, Class 2 Stranded
Nominal Cross Sectional Area	120 sqmm
Number of Cores	Typically 3, 3.5, or 4 cores
Rated Voltage	650/1100 V (1.1 kV)
Insulation	XLPE (Cross-Linked Polyethylene), rated 90°C continuous
Inner Sheath	PVC, Extruded Type ST2
Armouring Type
A2XWY – Galvanized Round Steel Wire (for flexibility)
A2XFY – Galvanized Flat Steel Strip (for higher crush strength)
Outer Sheath	Black PVC Type ST2 – Flame-Retardant & UV-Resistant
Standards Compliance	IS 7098 (Part 1):1988, IEC 60502-1
Country of Origin	India
Manufacturer	Havells India Ltd.,
