Havells 10.0 Sqmm Multicore Black PVC Insulated Copper Conductor Round Flexible Industrial Cable, ( 100MTR)

Havells 10.0 Sqmm Multicore Black PVC Insulated Copper Conductor Round Flexible Industrial Cable, ( 100MTR)

Rs. 30,204.00
Rs. 50,340.00 Rs. 30,204.00
Sale Sold out
Size
The Havells 10.0 Sqmm Multicore Black PVC Insulated Copper Conductor Round Flexible Industrial Cable (100 MTR) is a heavy-duty, high-conductivity flexible cable engineered for industrial power and control use. Manufactured to IS:694 standards and rated for 1100 V, it ensures reliable performance in demanding conditions such as heavy electrical loads, motors, and control panel wiring.

Key Specifications:

  • Brand: Havells

  • Conductor Material: Annealed bare copper, Class 5 (flexible) per IS:8130

  • Cross Section: 10.0 sq. mm

  • Number of Cores: Typically available in 2, 3, or 4 core configurations

  • Voltage Rating: 1100 V

  • Insulation Material: PVC Type D (Heat and Flame Retardant as per IS:5831)

  • Sheath Material: PVC Type ST-3 (Black, round extra-flexible sheath)

  • Nominal Insulation Thickness: 0.7 mm

  • Overall Diameter (4-core): Approx. 21.8 mm

  • Maximum Conductor Resistance (at 20°C): 1.83 Ω/km

  • Current-Carrying Capacity: 70–75 A (depending on installation conditions)

  • Temperature Range: -10°C to +70°C continuous operation
