Anchor Ziva 6A Single Pole C Type Mini MCB, 68980 (Pack of 6)

The Anchor Ziva 6A Single Pole C Type Mini MCB, model 68980, available in a pack of 6, is designed to provide reliable protection against overloads and short circuits in electrical circuits. It features a compact mini modular design, rated at 6 Amperes, with a C Curve trip characteristic. The MCB has a breaking capacity of 3 kA and operates at 240V AC with a frequency of 50 Hz.

Key Specifications

• Poles: Single Pole (1P)

• Rated Current: 6 Amperes

• Curve Type: C Curve (trips at 5-10 times rated current, suitable for moderate inrush currents)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Material: V0 Grade Flame Retardant Polycarbonate housing

• Color: Typically black or white (depending on series)

• Modules: 3M (modular width units)

• Standards: IS/IEC 60898-1 compliant

• Additional Features: Includes Do Not Disturb (DND) and MMR indicators for status indication

This MCB offers dependable circuit protection with compact dimensions and user-friendly indicators, making it suitable for residential and commercial electrical systems needing low-current protection.
