Anchor Ziva 32A Single Pole C Type Mini MCB, 68985 (Pack of 6)

The Anchor Ziva 32A Single Pole C Type Mini MCB, model 68985, available in a pack of 6, is designed for reliable circuit protection against overloads and short circuits. It features a single pole with a C Curve tripping characteristic suitable for general-purpose circuits with moderate inrush currents. This MCB has a rated current of 32 Amperes, a breaking capacity of 3 kA, and operates at 240V AC with a frequency of 50 Hz.

Key Specifications

• Poles: Single Pole (1P)

• Rated Current: 32 Amperes

• Curve Type: C Curve (trips at 5-10 times rated current)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Material: Flame-retardant polycarbonate housing

• Color: White

• Standards: IS/IEC 60898-1 compliant

Features

• Mid-trip indication to monitor fault conditions

• Trip-free mechanism prevents manual override during critical faults

• Compact design for easy installation and maintenance

This MCB from Anchor Ziva series is ideal for protecting household and commercial electrical circuits, offering trusted performance and safety in a compact module.
