Anchor Ziva 25A Single Pole C Type Mini MCB, 68984 (Pack of 6)

The Anchor Ziva 25A Single Pole C Type Mini MCB, model 68984, available in a pack of 6, is designed for effective electrical circuit protection against overloads and short circuits. It features a single pole, C Curve trip characteristic, rated current of 25 Amperes, and a breaking capacity of 3 kA. The device operates at 240V AC with a frequency of 50 Hz and complies with IS/IEC 60898-1 standards.

Key Specifications:

• Poles: Single Pole (1P)

• Rated Current: 25 Amperes

• Curve Type: C Curve (thermal-magnetic tripping suitable for moderate inrush currents)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Material: Flame-retardant polycarbonate housing

• Color: White

• Modules: 3M (modular width units)

• Standards: IS/IEC 60898-1 compliant

Features:

• Mid-trip indication for easy fault identification

• Trip-free mechanism to prevent manual override

• Compact size for easy installation and maintenance

This Anchor Ziva MCB is ideal for residential and commercial electrical applications requiring robust, reliable circuit protection at the 25A rating level.
