Anchor Ziva 20A Single Pole C Type Mini MCB, 68983 (Pack of 6)

The Anchor Ziva 20A Single Pole C Type Mini MCB, model 68983, available in a pack of 6, is designed for reliable protection against overload and short circuits in electrical circuits. It has a rated current of 20 Amperes with a C Curve trip characteristic, suitable for moderate inrush currents. The MCB has a breaking capacity of 3 kA and operates at 240V AC with a frequency of 50 Hz.

Key Specifications

• Poles: Single Pole (1P)

• Rated Current: 20 Amperes

• Curve Type: C Curve (trips at 5-10 times rated current, ideal for moderate inrush currents)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Material: Flame-retardant polycarbonate housing

• Compact Dimensions: Approximately 11.9 x 5.9 x 4.3 cm

• Modules: 3M (modular width units)

• Color: Usually white or black (depending on series)

• Standards: IS/IEC 60898-1 certified

Features

• Includes indicators like Do Not Disturb (DND) and Manual/Mechanical Reset (MMR)

• Mid-trip indication for easy fault detection

• Trip-free design to prevent manual override during fault conditions

• Compact and durable for easy installation and maintenance

This MCB from the Anchor Ziva series is a reliable solution for residential and commercial electrical protection requiring 20A rating and C Curve characteristics.
