Anchor Ziva 16A Single Pole C Type Mini MCB, 68982 (Pack of 6)

The Anchor Ziva 16A Single Pole C Type Mini MCB, model 68982, available in a pack of 6, offers efficient protection against overloads and short circuits for electrical circuits. It is a single-pole MCB with a C Curve tripping characteristic designed to handle moderate inrush currents. The MCB has a rated current of 16 Amperes, a breaking capacity of 3 kA, and operates at 240V AC with a frequency of 50 Hz.

Key Specifications

• Poles: Single Pole (1P)

• Rated Current: 16 Amperes

• Curve Type: C Curve (trips at 5-10 times rated current, suitable for moderate inrush)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Material: V0 Grade Flame Retardant Polycarbonate housing

• Modules: 3M (modular width units)

• Color: Black or White (depending on version)

• Standards: IS/IEC 60898-1 certified

Features

• Includes DND (Do Not Disturb) and MMR (Manual/Mechanical Reset) indicators for status

• Mid-trip indication for easy fault detection

• Trip-free mechanism to prevent manual override during faults

• Compact and durable design for easy installation and maintenance

This Anchor Ziva 16A Mini MCB ensures reliable and safe electrical protection in residential and commercial installations with trusted build quality and functional indicators.
