Anchor UNO 63A C Type Double Pole MCB, 98024 (Pack of 12)

The Anchor UNO 63A C Type Double Pole MCB, model 98024, available in a pack of 12, provides robust protection against overloads and short circuits for high-load applications. It features a double pole configuration rated at 63 Amperes with a C Curve trip characteristic suitable for moderate inrush currents. The MCB has a breaking capacity of 10 kA (10000A), operates at 240/415V AC with 50 Hz frequency, and measures 44.5 x 40.8 x 24 cm per pack with 0.54 kg weight.

Key Specifications

• Poles: Double Pole (2P)

• Rated Current: 63 Amperes

• Curve Type: C Curve (thermal-magnetic trip)

• Rated Voltage: 240/415 V AC

• Frequency: 50 Hz

• Breaking Capacity: 10 kA (10000A)

• Housing: Flame-retardant polycarbonate

• Mounting: Modular snap-fit or DIN rail

• Certification: IS/IEC 60898-1 compliant

• Manufacturer: Panasonic Life Solutions India Pvt. Ltd.

• Packaging: Pack of 12

Features

• Mid-trip indication to distinguish manual OFF from fault trips

• Positive contact indication (Red-ON, Green-OFF) for clear status

• Large 35 sq.mm terminal capacity with bi-connect for flexible wiring

This MCB is ideal for main distribution boards in residential, commercial, and light industrial settings handling heavy loads.
