Anchor UNO 32A C Type Double Pole MCB, 98022 (Pack of 12) oub

The Anchor UNO 32A C Type Double Pole MCB, model 98022, available in a pack of 12, provides reliable protection against overloads and short circuits. It features a double pole configuration rated at 32 Amperes with a C Curve trip characteristic suitable for moderate inrush currents. The MCB has a breaking capacity of 10 kA (10000A), operates at 240/415V AC with 50 Hz frequency, and uses flame-retardant polycarbonate housing.

Key Specifications

• Poles: Double Pole (2P)

• Rated Current: 32 Amperes

• Curve Type: C Curve (thermal-magnetic trip)

• Rated Voltage: 240/415 V AC

• Frequency: 50 Hz

• Breaking Capacity: 10 kA (10000A)

• Housing: Flame-retardant polycarbonate

• Color: White

• Mounting: DIN rail or modular snap-fit

• Certification: IS/IEC 60898-1 compliant

• Dimensions: 44.5 x 40.8 x 24 cm (pack)

• Packaging: Pack of 12

Features

• Mid-trip and positive contact indication for fault diagnosis

• Trip-free mechanism prevents manual override during faults

• Large termination (35 sq.mm) with bi-connect for flexible wiring

This MCB suits residential, commercial, and light industrial high-load circuits like main distribution boards.
