Anchor UNO 25A 6kA C Type Double Pole MCB, 99111 (Pack of 12)

The Anchor UNO 25A 6kA C Type Double Pole MCB, model 99111, available in a pack of 12, provides cost-effective protection against overloads and short circuits for residential and light commercial circuits. It features a double pole configuration rated at 25 Amperes with a C Curve trip characteristic suitable for moderate inrush currents and a breaking capacity of 6 kA (6000A). Manufactured by Panasonic Life Solutions India Pvt Ltd in India, it measures 3x4x10 cm with 94 g weight per unit.

Key Specifications

• Poles: Double Pole (2P)

• Rated Current: 25 Amperes

• Curve Type: C Curve (thermal-magnetic trip)

• Rated Voltage: 240/415 V AC

• Frequency: 50 Hz

• Breaking Capacity: 6 kA (6000A)

• Housing: Flame-retardant polycarbonate

• Color: White

• Dimensions: 3 x 4 x 10 cm

• Weight: 94 g

• Mounting: Modular snap-fit or DIN rail

• Certification: IS/IEC 60898-1 compliant

• Packaging: Pack of 12

Features

• Mid-trip indication distinguishes manual OFF from fault trips

• Compact design for domestic distribution boards

• Suitable for power outlets and appliances

This MCB is ideal for home applications where 6 kA capacity meets requirements.
