Anchor UNO 06A 6kA C Type Double Pole MCB, 99107 (Pack of 12)

The Anchor UNO 06A 6kA C Type Double Pole MCB, model 99107, available in a pack of 12, offers cost-effective protection against overloads and short circuits for low-power circuits. It features a double pole configuration rated at 6 Amperes with a C Curve trip characteristic suitable for moderate inrush currents and a lower breaking capacity of 6 kA, ideal for lighter residential applications compared to higher-rated 10 kA models. Manufactured by Panasonic Life Solutions India Pvt Ltd, it complies with IS/IEC 60898-1 standards and supports modular mounting.

Key Specifications

• Poles: Double Pole (2P)

• Rated Current: 6 Amperes

• Curve Type: C Curve (thermal-magnetic trip)

• Rated Voltage: 240/415 V AC

• Frequency: 50 Hz

• Breaking Capacity: 6 kA (6000A)

• Housing: Flame-retardant polycarbonate

• Color: White

• Mounting: Modular snap-fit or DIN rail

• Certification: IS/IEC 60898-1 compliant

• Packaging: Pack of 12

Features

• Mid-trip indication for fault diagnosis

• Positive contact indication (Red-ON, Green-OFF)

• Compact design with bi-connect terminals for flexible wiring

This MCB suits basic residential lighting and small appliance circuits where 6 kA capacity meets requirements.
