Anchor SPN DB

Key Features

• Type: Available in SPN (Single Pole with Neutral) and TPN (Triple Pole with Neutral) configurations.

• Number of Ways: 4 to 24

• Door: Double Door design for enhanced safety and easy maintenance.

• Enclosure: Powder-coated CRCA steel sheet, typically 0.8 mm thick, with a Regal Grey finish.

• Wiring Space: Large wiring space with raised neutral link for convenient wiring without congestion.

• Protection: IP42 protection against solid objects over 1 mm and falling water drops.

• Mounting: Suitable for both surface and flush mounting.

• Bus Bars: Copper bus bars, tin-plated for better conductivity.

• Standards: Complies with IEC 61439-3, IS 13032 & IS 8623.

• Additional Features: Supplied with factory-fitted masking sheets to protect components during plastering, detachable DIN rails with end stoppers, neutral and earth links, and level marks for installation guidance.

• Ambient Temperature: 0°C to 50°C.
