Anchor Roma Plus 32A SP C Type Mini Modular MCB, 89985 (Pack of 12)

The Anchor Roma Plus 32A Single Pole C Type Mini Modular MCB, model 89985, available in a pack of 12, offers reliable and efficient protection against overloads and short circuits. It is designed with a single pole configuration and rated at 32 Amperes with a C Curve tripping characteristic. This MCB features a breaking capacity of 3 kA, operates at 240V AC with a frequency of 50 Hz, and complies with IS/IEC 60898-1 standards.

Key Specifications

• Poles: Single Pole (1P)

• Rated Current: 32 Amperes

• Curve Type: C Curve (suitable for moderate inrush currents)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Material: Flame-retardant polycarbonate housing

• Mounting: Modular snap-fit or flush screw mounted

• Compliance: IS/IEC 60898-1 certified

• Color: White

• Packaging: Pack of 12

Features

• Mid-trip indication for easy fault identification

• Trip-free design to prevent manual override during faults

• Compact and ergonomic design for easy installation and long-term reliability

This MCB from the Anchor Roma Plus series is suitable for residential, commercial, and light industrial electrical applications requiring robust circuit protection at 32A rating.
