Anchor Roma Plus 20A SP C Type Mini Modular MCB, 89983 (Pack of 12)

The Anchor Roma Plus 20A Single Pole C Type Mini Modular MCB, model 89983, available in a pack of 12, provides reliable protection against overloads and short circuits in electrical installations. It features a single pole design with a rated current of 20 Amperes and a C Curve trip characteristic. This MCB has a breaking capacity of 3 kA and operates at 240V AC with a frequency of 50 Hz. It complies with IS/IEC 60898-1 standards for safety and performance.

Key Specifications:

• Poles: Single Pole (1P)

• Rated Current: 20 Amperes

• Curve Type: C Curve (thermal-magnetic tripping suited for moderate inrush currents)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Material: Flame-retardant polycarbonate housing

• Mounting: Modular snap-fit or flush screw mounted

• Compliance: IS/IEC 60898-1 certified

• Color: White

• Packaging: Pack of 12

Features:

• Mid-trip indication for easy fault diagnosis

• Trip-free design preventing manual override during faults

• Compact and ergonomic for installation ease and durability

The Anchor Roma Plus 20A MCB is suitable for safe and efficient circuit protection in residential, commercial, and light industrial settings.
