Anchor Roma Classic Uno 20A Double Pole C Curve White Mini Modular MCB, 98078 (Pack of 12)

The Anchor Roma Classic Uno 20A Double Pole C Curve White Mini Modular MCB, model 98078, available in a pack of 12, is engineered for robust electrical circuit protection against overloads and short circuits. It features a double pole configuration, rated at 20 Amperes with a C Curve trip characteristic ideal for moderate inrush currents. The MCB has a breaking capacity of 3 kA and is designed for 240V AC, 50 Hz systems. It includes a flame-retardant polycarbonate housing and complies with IS/IEC 60898-1 standards for safety and quality.

Key Specifications:

• Poles: Double Pole (2P)

• Rated Current: 20 Amperes

• Curve Type: C Curve (thermal-magnetic trip)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Housing: Flame-retardant polycarbonate

• Installation: Modular snap-fit or flush screw mounting

• Compliance: IS/IEC 60898-1 certified

• Color: White

• Packaging: Pack of 12

Features:

• Mid-trip indication for easy fault diagnosis

• Trip-free mechanism to prevent manual override during faults

• Compact, ergonomic design for easy installation and durability

The Anchor Roma Classic 20A Double Pole MCB is suitable for residential, commercial, and light industrial use where reliable and safe circuit protection is required.
