Anchor Penta Modular 6A Single Pole C Curve Graphite Black UNO Mini Modular MCB, 65980GB (Pack of 6)

The Anchor Penta Modular 6A Single Pole C Curve Graphite Black UNO Mini Modular MCB, model 65980GB, available in a pack of 6, provides circuit protection against overloads and short circuits in residential and commercial electrical systems. This MCB features a compact graphite black mini modular design, has a breaking capacity of 3 kA, and operates at a rated voltage of 240V AC with a frequency of 50 Hz.

Key Specifications:

• Poles: Single Pole (1P)

• Rated Current: 6 Amperes

• Curve Type: C Curve (thermal-magnetic tripping for moderate inrush currents)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Mounting: Modular snap-fit or screw-mounted

• Terminal Capacity: Supports cables up to 35 mm²

• Protection Class: IP20 with finger-proof terminals

• Compliance: IS/IEC 60898-1 certified

• Color: Graphite Black

• Manufacturer: Panasonic Life Solutions India Pvt. Ltd.

Features:

• Mid-trip indication for easy fault identification

• Trip-free mechanism to prevent manual override during faults

• Low watt loss for energy efficiency

• Flame-retardant body for enhanced safety and durability

• Compact and ergonomic design for simple installation and maintenance

This MCB combines the trusted quality of Panasonic technology with a modern graphite black design to deliver reliable and energy-efficient circuit protection for a variety of applications.
