Anchor Penta Modular 25A Single Pole C Curve Graphite Black UNO Mini Modular MCB, 65984GB (Pack of 6)

The Anchor Penta Modular 25A Single Pole C Curve Graphite Black UNO Mini Modular MCB, model 65984GB, available in a pack of 6, is designed to offer reliable protection against overloads and short circuits. It features a graphite black compact mini modular design with a breaking capacity of 3 kA, suitable for single-pole setups with a rated voltage of 240V AC and frequency of 50 Hz.

Key Specifications

• Poles: Single Pole (1P)

• Rated Current: 25 Amperes

• Curve Type: C Curve (trips at 5-10 times rated current, ideal for moderate inrush currents)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Mounting: Modular snap-fit or flush screw-mounted

• Terminal Capacity: Supports cable sizes up to 35 mm²

• Protection Class: IP20 with finger-proof terminals

• Compliance: IS/IEC 60898-1 certified

• Color: Graphite Black

• Manufacturer: Panasonic Life Solutions India Pvt. Ltd.

Features

• Mid-trip indication for clear fault identification

• Trip-free mechanism to prevent manual override during fault conditions

• Low watt loss for energy efficiency

• Flame-retardant polycarbonate housing for safety and durability

• Compact ergonomic design for easy installation and maintenance

This MCB brings Panasonic's trusted technology and advanced safety features in a sleek graphite black design suitable for a variety of residential, commercial, and light industrial electrical applications.
