Anchor Penta Modular 25A Double Pole C Curve White UNO Mini Modular MCB, 65993 (Pack of 6)

The Anchor Penta Modular 25A Double Pole C Curve White UNO Mini Modular MCB, model 65993, available in a pack of 6, provides reliable protection against overloads and short circuits. It features a double pole configuration rated at 25 Amperes with a C Curve trip characteristic suitable for moderate inrush currents. The MCB has a breaking capacity of 3 kA (3000A), operates at 240V AC with 50 Hz frequency, and uses flame-retardant polycarbonate housing for safety.

Key Specifications

• Poles: Double Pole (2P)

• Rated Current: 25 Amperes

• Curve Type: C Curve (thermal-magnetic trip)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Housing: Flame-retardant polycarbonate

• Color: White

• Mounting: Modular snap-fit

• Certification: IS/IEC 60898-1 compliant

Features

• Mid-trip indication for easy fault detection

• Trip-free mechanism prevents manual override during faults

• Compact design with IP20 protection for energy efficiency

This MCB is suitable for residential, commercial, and light industrial applications requiring efficient circuit protection at 25A rating.
