Anchor Penta Modular 20A Single Pole C Curve Graphite Black UNO Mini Modular MCB, 65983GB (Pack of 6)

The Anchor Penta Modular 20A Single Pole C Curve Graphite Black UNO Mini Modular MCB, model 65983GB, available in a pack of 6, provides reliable protection against overloads and short circuits. This MCB features a compact graphite black mini modular design with a breaking capacity of 3 kA, suitable for single-pole applications at a rated voltage of 240V AC and frequency of 50 Hz.

Key Specifications:

• Poles: Single Pole (1P)

• Rated Current: 20 Amperes

• Curve Type: C Curve (thermal-magnetic trip suitable for moderate inrush currents)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Mounting: Modular snap-fit or flush screw-mounted

• Terminal Capacity: Supports cables up to 35 mm²

• Protection Class: IP20, finger-proof terminals

• Compliance: IS/IEC 60898-1 certified

• Color: Graphite Black

• Manufacturer: Panasonic Life Solutions India Pvt. Ltd.

Features:

• Mid-trip indication to easily identify fault conditions

• Trip-free mechanism prevents manual override during faults

• Low watt loss for energy-efficient operation

• Flame-retardant polycarbonate housing for enhanced safety and durability

• Compact and ergonomic design for easy installation and maintenance

This MCB from the Anchor Penta UNO series combines Panasonic’s trusted technology, robust safety features, and modern graphite black aesthetics, making it ideal for various residential and commercial electrical applications.
