Anchor Penta Modular 16A Single Pole C Curve White UNO Mini Modular MCB, 65982, (Pack of 6)

The Anchor Penta Modular 16A Single Pole C Curve White UNO Mini Modular MCB, model 65982, available in a pack of 6, is designed to protect electrical circuits from overloads and short circuits. It features a white compact mini modular design with a breaking capacity of 3 kA and is suitable for single-pole applications with a rated voltage of 240V AC and frequency of 50 Hz.

Key Specifications:

• Poles: Single Pole (1P)

• Rated Current: 16 Amperes

• Curve Type: C Curve (thermal-magnetic tripping suitable for moderate inrush currents)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Mounting: Snap-fit or flush screw-mounted on modular plates

• Terminal Capacity: Supports up to 35 mm² cable size

• Protection Class: IP20, finger-proof terminals

• Compliance: IS/IEC 60898-1 certified

• Color: White

• Manufacturer: Panasonic Life Solutions India Pvt. Ltd.

Features:

• Mid-trip indication for easy identification of fault conditions

• Trip-free mechanism prevents manual override during faults

• Low watt loss design for energy efficiency

• Flame-retardant polycarbonate housing for enhanced safety and durability

• Compact ergonomic design for easy installation and maintenance

This MCB from the Anchor Penta UNO series combines trusted Panasonic technology with a compact design to provide efficient and durable circuit protection across varied residential and commercial applications.
